(Please do NOT call it 'ampage' - use the term 'current')

Current has the symbol: I . Take care when you write this out. If you omit the line on the top and bottom your symbol could easily get confused with a lower case 'L' or the number 1. Start off with good habits and you will find that you automatically write it in an unambiguous manner forever!

Unit of current

Current ( I ) is measured in amperes or amps after Monsieur Ampère.

The abbreviation for this unit is: A

Measuring current

The instrument used to measure current is an ammeter - it is always put in series with the component it is requied to measure the current through....

Symbol:

Definition:

Current is the rate at which charge is moving past a point in a circuit.

Equation:

This means that if you find out the quantity of charge (Q) that travels past a point in a second (time - t) and divide Q by t you get the current - an amp is a coulomb per second.

When finding out how much charge flows you have to add all of the charge carried by particles (such as electrons or ions) that goes in one direction and take away the charge that goes in the other direction.

Charge (Q) is measured in coulomb (C) after Monsieur Coulomb.

What is the 'charge'?

In electrical circuits the 'charge' that moves in a wire is made up of electrons. They are made to drift down a potential gradient (a sort of 'electrical slope' that they slide down) when a battery or power source is connected in a complete circuit. See potential difference.

Electron flow is actally in the opposite direction to conventional current. Conventional current flow was decided upon as positive terminal to negative terminal way before they knew that electrons were moving in the wire or that they were negative and actually moving towards the positive terminal!

If you are dealing with a solution then the charge is made up of ions and you have to take into account the charge number on each ion and the direction it travels when working out a current.

Each electron carries a very small charge (1.6 x 10^-19C = 0.000 000 000 000 000 000 16C). It is used as a tiny charge quantity for calculations - saves using the calculator with loads of exponent terms!

e = 1.6 x 10^-19C

When a current of 1A flows in a wire over 6 million, million, million electrons are moving past each point on the wire every second!

A current of 1A is a quite a big current.

Most domestic electrical appliances use much smaller currents... measured in milliamps or microamps. Make sure you know your SI Prefixes

Why does current flow?

Current flows when there is an electric potential gradient (an 'electric slope') between two points on a conductor. The charged particles (sometimes called 'charges') within the conductor move down the gradient - they 'slide down the slope'.

The 'steeper the slope' the faster the charges move and the bigger the current that flows (see potential difference)

The more charges within the 'sloped' conductor the more charges move in a given time, so the faster the rate of flow of those charges and the bigger the current.



The bigger the potential difference the bigger the current, the bigger the resistance to current, the smaller the current.

For a current to flow there must be a complete circuit

If there is a break in a strand of a circuit no current can flow because there isn't a potential differece across the components in that strand. An open switch in any strand will stop current flowing through it and therefore mean that all of the components in that strand have no current flowing through them.

The position of the switch does not matter. If it is open the WHOLE strand has no current flowing through it.

If the switch is in the same strand as the power supply it can be used to cut off the current flow in the whole circuit.

If the switch is in an isolated strand it just 'takes out' that strand.

Try placing a switch in a few different places in circuits modelled in software such as Crocodile Physics - ask, you probably have it (or something similar) on your school system.

Design a circuit with three bulbs in parallel so that one switch will switch them all on or off at once.

Design a circuit with three bulbs in parallel so that each has an individual switch to switch it off or on.

Design a circuit with three bulbs in series so that one switch will switch them all on or off at once.
