Transformer Crossword

1d This flows through the coils when a voltage is applied

2a This type of transformer produces a bigger output voltage than input voltage

2d This type of transformer produces a smaller output voltage than input voltage

3d Opposite of output

4a This word describes the construction of the core. It cuts down the [6d] currents

5d An alternating [5d] needs to be input into a transformer

6d See [4a]

7a and [9d] is the term that describes how a voltage is induced by the movement of a wire relative to magnetic field lines so that the wire 'cuts the lines of magnetic flux'

8d A low resistance metal that the coil windings are made of.

9d See [7a]

10a The name given to the output coil

11d The name of the object the wire is wrapped around

12d A primary coil has more of these than a secondary coil in a stepdown transformer

13a The name given to the input coil

14d Metal the core is made of

15a Word that describes the magnetic properties of [15a]

16a Transformers are about 99% this!

17a Another name for [12d]

ANSWERS
