Geothermal Energy

'Geothermal' comes from the Greek words 'geo' (earth) and 'therme' (heat). It means 'the heat from the earth'. >

The heat in the Earth's interior originated from its formation as part of the Solar System from dust and gas over 4 billion years ago. It was then very hot but over time that heat energy is radiated into space. However within the Earth are radioactive elements that decay and 'top up' the heat energy content of the Earth.

Geothermal resources range from those warm in shallow ground, to hot water warmed by rock several miles below Earth's surface, and even further down to the extremely high temperatures of molten rock itself called magma.

The Earth's energy can be used as heat that is transferred directly or it can be converted into electricity.

The three technology categories for its use are:

geothermal heat pumps,

direct-use applications, and

power plants (converting the energy to electical enery for distribution via an electricity grid).

Domestic Power from Geothermal Heat Pumps - Use of Shallow Ground Energy to Heat and Cool Buildings

The earth absorbs almost 50% of all the solar energy that falls on it and remains a nearly constant temperature of 10°C to 16°C depending on geographic location.

Working with an underground loop system, geothermal heating and cooling systems utilize this constant temperature to exchange energy between domestic homes and the earth as needed for heating and cooling.

In winter, water circulating inside a sealed underground loop system absorbs heat from the earth and carries it to the geothermal unit. Here it is compressed to a higher temperature and sent as warm air to your indoor system for circulation throughout the home.

In the summer, the system reverses and expels heat from your home into the cooler earth via the loop system.

This heat exchange process is not only natural, but is a natural and highly efficient way to create a comfortable climate in the home.

There are several loop options that can be employed. They can either be vertical, horizontal, or submerged in a nearby pond or lake. In many cases, a water well can be used instead.

The best application will depend on the characteristics of the property.

Direct-Use Piped Hot Water

Hot water near Earth's surface can be piped directly into facilities and used to heat buildings, grow plants in greenhouses, warm water for fish farming, and to pasteurize milk.

Some cities in the USA pipe the hot water under roads and sidewalks to melt snow.

District heating applications use networks of piped hot water to heat buildings in whole communities.

Power Plants Generate Electricity from Geothermal Reservoirs

A geothermal power plant in CaliforniaWells (a mile or more in depth) can be drilled into underground reservoirs to tap steam and very hot water. The pressure from the steam generated by this drives turbines that drive electricity generators.

Three types of power plants are operating today:

Dry steam plants, which directly use geothermal steam to turn turbines;

Flash steam plants, which pull deep, high-pressure hot water into lower-pressure tanks and use the resulting flashed steam to drive turbines; and

Binary-cycle plants, which pass moderately hot geothermal water by a secondary fluid with a much lower boiling point than water. This causes the secondary fluid to flash to steam, which then drives the turbines.

Domestic geothermal energy use:
