Questions on Electric Circuits

Q7.The diagram shows a circuit for controlling an electric motor. This circuit can make the motor turn forwards or backwards.

Complete the table to show which lamp, if any, is lit and in which direction, if any, the motor turns. The first row has been done for you.

Switch A	Switch B	Which lamp, if any, is lit?	Motor direction (forwards or backwards)
up	down	Lamp 1	forwards
up	up
down	up
down	down

3 marks
